Full
Music 300B/n
specifications
|
Fullmusic
TJ 300B/n globe
| 300B/n
Premium mesh plate |
|
| |
|
| Nominal
operating conditions and parameters |
|
| |
|
| Filament
voltage |
5
V* |
| Nominal
filament current |
1.2
A |
| Plate
voltage |
300
V |
| Grid
voltage |
-58
V** |
| Plate
current |
60
mA |
| Amplification
factor |
3.85 |
| Mutual
Conductance |
5,7
mA/V |
| Grid
current |
0.05
µA |
| Plate
resistance |
700
ohms |
| |
|
*AC
filament supply or DC filament supply.
**AC filament supply is used.
|
|
|
|
|
