Neotech
UP-OCC hook-up wire





Silver wire

Neotech, Ultra Pure Onho Continuous Cast (UP-OCC).
 Can be used for speaker wire, mains cable, interconnect and general hook up wire.

Solid Core




Solid Core UP-OCC silver wire, coated in blue TEFLON insulation.
Teflon provides excellent insulation and dielectrics for the single core.


Part No.
AWG
Diameter
(mm)
Current rating
Isolation
Outer Diam.
(mm)
Price per meter
ex.VAT
Price per meter
incl .VAT

SOST-18
18
1.03
blue teflon
1.75
78.35
94.80
SOST-22
22
0.65
300V/6,3A
blue teflon
1.35
36.36
44.00
SOST-24
24
0.52
300V/5,4A
blue teflon
1.25
25.06
30.30
SOST-28
28
0.32
300V/3,0A
blue teflon
1.05
9.42
11.40
SOST-30
30
0.25
300V/1,9A
blue teflon
0.90
6.90
8.35





Copper wire

Neotech, Ultra Pure 7N Onho Continuous Cast (UP-OCC).
Can be used for speaker wire, mains cable, interconnect and general hook up wire

Solid Core




Solid core UP-OCC 7N copper wire coated in red TEFLON insulation.
Teflon provides excellent insulation and dielectrics for the single core that is 99.99999% pure copper.

Part No.
AWG
Diameter
(mm)
Current rating
Isolation
Outer Diam.
(mm)
Price per meter
ex.VAT
Price per meter
incl .VAT

SOCT-18
18
1.03
300V/12,5A
red teflon
1.75
7.23
8.75
SOCT-20
20
0.82
300V/9,4A
red teflon
1.55
out of stock
SOCT-22
22
0.65
300V/7,0A
red teflon
1.35
3.47
4.20
SOCT-24
24
0.52
300V/5,4A
red teflon
1.25
2.85
3.45
SOCT-26
26
0.40
300V/2,9A
red teflon
1.10
2.48
3.00
SOCT-28
28
0.32
300V/1,8A
red teflon
1.05
2.23
2.70







Solid core UP-OCC 7N copper wire coated in PVC.

Part No.
AWG
Diameter
(mm)
Current rating
Isolation
Outer Diam.
(mm)
Price per meter
ex.VAT
Price per meter
incl .VAT

SOCP-12
12
2.06
600V/30A
Pearl White
4.0
17.02
20.60
SOCP-14
14
1.63
600V/22A
Pearl Green
3.5
11.28
13.65
SOCP-16
16
1.30
600V/16A
Pearl Yellow
3.1
7.52
9.10
SOCP-18
18
1.03
600V/12,5A
Pearl Silver
2.8
4.71
5.70
SOCP-20
20
0.82
600V/9,4A
Pearl Blue
2.6
3.02
3.65
SOCP-22
22
0.65
600V/7,0A
Pearl Black
2.4
2.15
2.60
SOCP-24
24
0.52
600V/5,4A
Pearl Red
2.2
1.53
1.85



Stranded Core




Stranded core UP-OCC 7N copper wire coated in PVC

Part No.
AWG
Diameter
(mm)
Strands
Isolation
Outer Diam.
(mm)
Price per meter
ex.VAT
Price per meter
incl .VAT

STDCP-16
16
1.30
19 x 0,30mm
Pearl Yellow
3.1
8.47
10.25
STDCP-18
18
1.03
19 x 0,25mm
Pearl Silver
2.8
6.61
8.00
STDCP-20
20
0.82
7 x 0,32mm
Pearl Blue
2.6
3.76
4.55
STDCP-22
22
0.65
7 x 0,25mm
Pearl Black
2.4
2.60
3.15



Stranded Litze wire





Neotech EC-UPOCC multi-stranded copper Litz coated wire in COTTON.
Ideal for interconnects and speaker cables.
Each strand of wire is polyurethane coated, so this needs to be removed before the wire starts conducting. You can remove the coating by using a solder bath or running the wire through a bubble of molten solder on the end of a soldering iron

Part No.
AWG
Diameter
(mm)
Strands
Current rating
Outer Diam.
(mm)
Price per meter
ex.VAT
Price per meter
incl .VAT

ROUCC-22
22
0.65
68 x 0,08mm
5,4A
1.7
8.80
10.65
ROUCC-24
24
0.52
41 x 0,08mm
3,8A
1.7
6.28
7.60
ROUCC-26
26
0.40
26 x 0,08mm
2,7A
1.7
4.42
5.35






Neotech UP-OCC


Neotech has been producing outstanding cables since 1980, and has long been a leader in producing wire and cable using "single crystal" UP-OCC, developed by Professor Ohno of the Chiba Institute of Technology in Japan. UP-OCC is at least 99.99998% pure, and has an average crystal size of 125 meters (410 feet)! Compare this to the average crystal size of Oxygen Free, which is .02 meters (3/4").

UP-OCC copper and silver are considered the ultimate in copper and silver conductior technology today.
.



The unidirectional UP-OCC has no electric resistance and practically no crystal boundaries. Accordingly, it is able to transmit electrical signals faster and with less distortion than ordinary OFC and silver wires. All of these features make the pure OCC copper and silver the state-of-the art conductor materials for the audiophile cable industry
